| Part No. | Description |
|---|---|
| 11020638 | Hand Brake Arrangement |
| 11360290 | Brake Hand with Chain |
| 11368792 | Housing Assy. |
| 11268871 | Bush on left side plate |
| 11368925 | Bush on right side plate |
| 11369322 | Screw Housing Cover 1/4” - 20UNC 2A x 1/2” long |
| 11369310 | Washer spring lock cover 1/4in. |
| 11369280 | Cover |
| 11369048 | Drum chain |
| 11369097 | Shaft Assy, Chain Drum |
| 11369012 | Shaft |
| 11369115 | Bush |
| 11369127 | Steel ball |
| 11369139 | Spring |
| 11369050 | Bushing Chain Drum |
| 11369220 | Pinion |
| 11369231 | Ratchet Pinion |
| 11369243 | Retainer Pinion |
| 11369292 | Screw Hex. Hd. 3/8”-16UNC- 2A 1 Lg. |
| 11369309 | Washer spring lock 3/8” 1/16 thick |
| 11368960 | Pawl, Holding |
| 11369012 | Shaft Holding Pawl & Trip Lever |
| 11368986 | Spring Holding Pawl |
| 11368974 | Pin Holding Pawl 1/2” -11UNC -2A |
| 11368998 | Spindle, Spring holding |
| 11369000 | Pin, Spindle Holding Pawl Spring |
| 11369024 | Lever, Trip |
| 11369036 | Spring, Trip Lever |
| 11369140 | Hand Lever Assy. |
| 11369164 | Pawl, Hand Lever |
| 11369176 | Shaft, Hand Lever Pawl |
| 11369138 | Spring, Hand Lever Pawl |
| 11369190 | Screw, 1/4”-UNC 2A 3/8” long |
| 11369310 | Washer, 1/4” Spring lock |
| 11369206 | Ratchet, hand Lever |
| 11369218 | Screw, Adjusting Hand Lever 3/8”-UNC - 2A X 1-1/2” long |
| 11369073 | Chain, Link |
| 11369061 | Chain, Egg, Link |
| 11369334 | Joines |
| 11369255 | Snubber, Chain |
| 11369267 | Weight, chain Snubber |
| 11369279 | Pin, Chain Weight |
| 11369085 | Chain |
| 11340563 | Chain for Hand Brake |
| 11020647 | Support Lever |
| 11020659 | Sheave Support Assy. |
| 11020660 | Lever Assy |
| 11100618 | Chain Trough |
| 11100620 | Chain Trough |
| 11160779 | Pin |
| 11100631 | Chain Guard |
| 11020672 | Sheave Cover Assy. |
| 11160767 | Pin |
| 11020684 | Pin |
| 11160809 | Pin |
| 11020696 | Pin |
| 15326196 | Cotter Pin 5/16”x2-1/2” long |
| 15390238 | Plain Washer 1-1/8” |
| 11230708 | Clevis |
| 11250215 | Sheave |
| 11020202 | Hand Brake Bracket Assy. |
| 15017151 | Bolt Hex Hd. 5/8” - 11x1-3/4” long |
| 15396162 | Spring Lock Washer 5/8” |
| 15390240 | Plain Washer 1-1/4” |
| 15330175 | Roll Pin |
| 15159050 | Machine Screw, Rd. Hd. |
| 15396101 | Spring, Lock Washer 1/4” |
| 15363107 | Lock Nut 1/4”-20 |
| 11123916 | Lever Support Stiffener |
| 15230028 | Wood Screw |
