BASE (ENGINE) WITH SCREEN AND COVERS

Part No.Description
10020100Base engine
10240202Plate,wear,engine mounting,free end
10180667Screw generator end
10020081Screen assy
10026093Screen assy.
10180590Screen with capscrew,crank pin Nos.1,2,3,4
10180631Screen with slots,crank pin 1,2,3,6,7,8
10180606Screen with capscrews ,crank pin ,4,5,6,7,8
10180620Screen with plug opening,crank pin Nos.5 L.S
10180613Screen,Crank pin no. 4 center,right and L.S
15377120Lock Nut.for screw,3/8"­16
15410080Washer 3/8"
15031070Capscrew,end screen to base,3/8"­16x3./4" long
15410080Washer 3/8"
15393124Lock Washer 3/8"
15031111Capscrews,screen to base,3/8"­10x1­1/4" lg.
15031159Capscrew,screen to base,3/8"­16*1­3/4" long.
15377120Lock Nut 3/8"­16"
15410080Washer 3/8"
10020111Pipe lubricating oil depth gauge
10020159Lube oil depth gauge assy.
10180497Depth Gauge Lubricatings
10240871Washer 7/16"
10170662Gasket
10020240Plug,drain lubricating oil
10061022Header,lubricating oil to main brg.
10212528Pipe plug,1"IPS CSK
10170273Gasket,header to base
15086150Capscrew,header to base,5/8­11*1­3/4" soc hd.
15397166Lock washer 5/8"
10190703Support,L.O. Header
15031135Capscrew ,support to base,3/8"­16*1­1/2" lg.
15377120Lock Nut 3/8"­16
10180370Washer Plate
15049190Capscrew,header to support 1/2"­13*2­1/2" long.
15351142Nut slotted,1/2"­13
15321083Cotter pin,3/32"*7/8"
15390147Washer 1⁄2"
10060029Fitting,spl.at L.O. Header
10020172Cover,with bar generaor end
10190934Cover only
10191367Bar, locking
10220604Bolt
10170133Srare­o­Seal
15329094Pin cotter
10170674Gasket
10020275Safety cover assy(use only with old base)
10195154Frame,safety cover gen.end
10181350Covers, safety covers
10171496Gasket,cover to shield
10181969Shield,safety covers
10171370Gasket ,cover to base
15031093Capscrew,safety cover to base,5/8­16*1" long.
15393124Lock washer,3/8"
10180618Washer,spl. Lube Oil drain plug
15322178Pin,cotter L.O. Drain plug 3/16"­2" long.
10020123Cover,base wth Gasket(cast aluminium)
10130184Cover only
10130196Knob with spindle
10120622Bar locking
10160097Spring locking
15354167Nut,5/8"­11 sq. hd.
15322130Pin,cotter,nut to spindle,3/16"*1­1/2" lg.
15363168Nut ,elastic stop ,5/8"­11
10170248Gasket,cover to base
10020184Explosion door assy.
10130275Explosion door
10190223Cover plate
10170236Gsket(cover plate to door)
15031378Capscrew 3/8­16*7"(cover plate to door)
15373125Acorn nut 3/8"­16
10210076spacer
10160085spring
10191343Locking bar
10221049Special capscrew
10211299Special washer
15329112Cotter Pin 1/8" dia x 1-1/4" long
10170248Gasket(door to base)
